Trapezoidal Shear Cut To Length Line

Introduction to Trapezoidal Shear Cut to Length Line

KINGREAL SLITTING trapezoidal shear cut to length line, relying on its core oscillating shearing technology, has become a core specialized equipment for the mass production of irregularly shaped metal sheets. Based on the principle of precise angle oscillating shearing, the trapezoidal shear cut to length machine can flexibly adapt to various sheet material shapes, producing trapezoidal, parallelogram, triangular, and various irregular metal blanks, meeting the customized production needs of various industries for irregularly shaped sheets in one stop.

The trapezoidal shear cut to length line uses a CNC system to precisely set the shearing angle, driving the cutter head to complete an arc-shaped oscillation motion, dynamically shearing continuously moving metal coils to a fixed length. It produces irregularly shaped sheets with regular shapes and precise dimensions without the need for secondary cutting.

Currently, the trapezoidal shear cut to length machine is widely used in automobile manufacturing, building materials, home appliances, and general hardware metal processing.

Parameters of Trapezoidal Shear Cut to Length Machine

| As the core of the KINGREAL SLITTING trapezoidal shear cut to length line, it selects electrical components from top-tier brands such as Weinviewe, Fateke, and Inovance. These components have strong anti-interference capabilities, fast response speed, and stable operation, accurately matching the servo oscillating shearing motion and eliminating problems such as operational jamming, angle deviation, and start/stop failures.

Meanwhile, the mechanical load-bearing components, precision pneumatic components, hydraulic transmission system, and other core components of the trapezoidal shear cut to length machine all use high-standard brand components in the industry. All components undergo multiple pressure resistance, wear resistance, and aging resistance tests before leaving the factory.

The combination of high-quality branded components significantly reduces the failure rate of the trapezoidal shear cut to length machine, effectively minimizing equipment downtime for maintenance and ensuring long-term, stable operation of the production line. |

Highlights of Trapezoidal Shear Cut to Length Line

1. Mass Production of Irregularly Shaped Sheets

KINGREAL SLITTING trapezoidal shear cut to length machine, through CNC angle adjustment system, can freely switch shearing angles, precisely producing large batches of trapezoidal, triangular, parallelogram, and various irregularly shaped metal blanks. The sheets are flat, with neat edges and corners, free of burrs and deformation, perfectly adapting to the production needs of various irregularly shaped work-pieces.

2. Adaptability to Automotive Precision Manufacturing

The trapezoidal shear cut to length machine is specifically optimized for automotive industry processing scenarios, highly adaptable to the production needs of automotive OEMs and Tier 1 and Tier 2 component suppliers.

It can directly mass-produce irregularly shaped blanks that meet automotive component standards, which are then processed into core components such as car body shells, chassis stampings, beams, and body panels. Eliminating secondary processing steps significantly improves production accuracy and capacity, making it a core mainstay equipment for automotive metal component processing.

3. Highly Efficient and Precise Dynamic Swing Shearing

The core of the trapezoidal shear cut to length line is equipped with a self-optimized swing shear mechanism. The blade holder completes the swing shearing action with a lever-arc motion trajectory. Combined with a high-precision servo synchronous control system, it can achieve dynamic synchronization with the continuously moving sheet material. Even with uninterrupted sheet material feeding, it instantly completes precise shearing, and then the blade holder quickly returns to its original position for the next work cycle.

The entire process requires no machine downtime and no manual intervention, ensuring a high-speed production cycle of 80m/min while effectively avoiding problems such as sheet material stretching, deformation, and dimensional deviations, resulting in consistent and stable sheet material quality.



4. Excellent Production Compatibility

The KINGREAL SLITTING trapezoidal shear cut to length machine can handle both irregularly shaped and regular rectangular sheets. The equipment can adjust the shearing angle with a single button via the CNC system. A 30° angle for precise cutting can meet the production needs of various trapezoidal sheets, while a 90° vertical shear can process standard rectangular sheets. It can also adapt to various custom-angled irregularly shaped blanks.

A single trapezoidal shear cut to length line can cover all the production needs of a company for both standard and irregularly shaped sheet metal, eliminating the need to purchase multiple machines and significantly saving on equipment procurement costs and space. It is suitable for both small and medium-sized processing plants engaged in large-scale production and large enterprises with diversified customized production scenarios.

Applications of Trapezoidal Shear Cut to Length Lines

KINGREAL SLITTING trapezoidal shear cut to length machines are deeply adaptable to various industries' deep processing scenarios for metal sheet metal, empowering the automation upgrade of various industries.

• Automotive Industry:

  Trapezoidal shear cut to length lines are mainly used for high-precision shearing of work-pieces such as automotive beams, side panels, chassis parts, and irregularly shaped stamping blanks. The formed blanks meet accuracy standards and have good consistency, allowing them to directly enter subsequent stamping and assembly processes, adapting to the standardized production of automotive parts.

• Home Appliance Industry:

  For metal casings, shells, and inner lining panels of home appliances such as refrigerators, washing machines, and air conditioners, trapezoidal shear cut to length machines can accurately cut various irregular and rectangular sheet metals, producing smooth, burr-free surfaces that meet the refined appearance and assembly requirements of home appliance parts.

• Steel structure construction industry:

  Trapezoidal shear cut to length lines can efficiently process building materials such as floor decking, color steel plates, truss panels, and decorative irregular-shaped panels. They offer flexible processing specifications, adapting to the diverse panel requirements of construction projects and facilitating efficient steel structure construction.

• Hardware products industry:

  Widely used for blanking processing of chassis, metal cabinets, and home metal accessories, they can adapt to the forming of various irregular-shaped hardware blanks, offering high processing efficiency and low waste, suitable for mass customization of hardware products.

Product Display

Successful Cut to Length Line Projects

For the differentiated production needs of clients in Russia and Indonesia, KINGREAL SLITTING tailored three cut to length line solutions with different parameters and performance configurations.

In the early stages of the project, the KINGREAL SLITTING team combined the client's actual production capacity planning, the thickness, width, and material requirements of the processed panels, as well as local industrial production policies and standards, to precisely customize simply cut to length lines and heavy gauge cut to length line, comprehensively matching the client's personalized production scenarios.

Meanwhile, KINGREAL SLITTING provides customers with a one-stop, end-to-end service, including pre-sales solution customization, equipment assembly and commissioning during sales, after-sales installation and training, lifetime spare parts supply, and regular equipment maintenance, ensuring stable production and efficient operation of the cut to length machine throughout the entire process.

The comprehensive customized solutions and attentive full-cycle service allow customers to truly experience KINGREAL SLITTING brand strength and service quality, resulting in all implemented projects achieving stable production and extremely high customer satisfaction.
